Optional ASCAND Apps for some extra hardware control and comfort
Enhanced Experience with the ASCAND Mobile App – Free on the App Store
The ASCAND 3D Scan Platform runs flawlessly in any web browser, but we’ve taken it a step further! Our mobile app, available for free on the App Stores, unlocks additional camera controls and exclusive phone-based features that aren’t possible in a browser.
Download it today and enjoy an even smoother scanning experience—on us!
Printable Accessories
Make scanning black objects easier with the white tabletop
Scanning black objects on a black table in a dark environment can make it tricky for the scanner to detect the bottom surface. That’s where our white tabletop solution comes in!
Simply download and print this PDF, print it using its EXACT SIZE WITHOUT SCALING, place it on your ASCAND turntable, and reapply your Magic Turntable Sleeve Ring. This simple fix enhances visibility, ensuring better scan accuracy.
Boost scan accuracy with the ASCAND laser alignment sheet
Download and print our Laser Alignment Sheet (PDF), cut it out, and place it on your ASCAND turntable. Then just align your laser line with the guide markings on the sheet. For best results, place two LEGO® bricks at the center point—this ensures perfect vertical alignment.
With this quick setup, your ASCAND Laser Extension Kit will be tuned for precise, detailed scans every time.
3D-Printable Parts & Accessories
MINI
MINI Table Adapter
This is the adapter, that allows you to center the 90mm MACRO Table on your 200mm ASCAND Turn Table and hold it in place.
MINI Table
This is a mini 90mm set-top turn table that is placed and centered on your ASCAND Turn Table using the MACRO Table Adapter.
MINI Table Sleeve Ring
This is the mini MACRO version of your Magic Sleeve Ring. Stick your MACRO Magic Sleeve on it and place it onto your MACRO Table for MACRO Scans
MAX 30 / MAX 40
MAX Laser Bracket
Easily attach your ASCAND Laser Holder and Phone Stick to the turntable with this Laser Bracket. The design even includes space to securely hold your Battery Case, ensuring a streamlined and organized setup for your 3D scanning process..
MAX Phone Stick
This extended version of the standard ASCAND Phone Stick is designed to provide the extra distance needed between your Phone Holder and the Turntable when using the MAX adapters. Perfect for achieving optimal positioning during larger object scans.
MAX30 Turn Table Adapter
Simply place this Turntable Adapter onto the standard ASCAND Turntable and add a 3mm thick black felt circle with a 300mm diameter on top. This setup expands your scan area to 300mm, giving you more surface space for larger objects and improved scanning flexibility
MAX30 Sleeve Ring
The MAX30 Sleeve Ring sits atop the Turntable Adapter and felt surface, providing a sturdy base for larger scans. Simply attach the Magic Sleeve for the MAX30 to this ring, and you’re ready to take on bigger projects with ease.
MAX40 Turn Table Adapter
Simply place this Turntable Adapter onto the standard ASCAND Turntable and add a 3mm thick black felt circle with a 400mm diameter on top. This setup expands your scan area to 400mm, giving you more surface space for much larger objects and improved scanning flexibility.
MAX40 Sleeve Ring
The MAX40 Sleeve Ring sits atop the Turntable Adapter and felt surface, providing a sturdy base for much larger scans. Simply attach the Magic Sleeve for the MAX30 to this ring, and you’re ready to take on even bigger projects with ease.
ASCAND Print Plates
VISION Production Plate
The ASCAND VISION Production STL consists of the ASCAND Sleeve Ring, the Phone Holder, and the Calibration Card Holder.
It MUST be printed in WHITE PLA or PETG. After printing you need to carefully attach the Standard ASCAND Magic Sleeve to it.
It needs about 43g of Filament and should print in 1-2 hours on a recent consumer grade 3D printer.
LASER Production Plate
The ASCAND Laser Expansion Kit Production STL consists of the ASCAND Laser Bracket, the Laser Holder, the Phone Stick, and the Side Stick.
You can 3D print it using PLA in any color you like.
It needs about 52g of Filament and should print in 1-2 hours on a recent consumer grade 3D printer.
Print Settings
All files for the ASCAND 3D scanner are designed to be 3D-printed on most standard consumer 3D Printers with easy-to-use, widely-available, affordable PLA+ at a minimum temperature of 215C. A standard 0.4mm nozzle is fine. Infill does not matter.
You can print the Plate in any color your like as long as you are not getting too glossy. However, the Turn Table Sleeve Ring HAS TO BE printed in WHITE to avoid the white bits of the Block Code Tape from being “recolored” by a Turn Table Sleeve Ring color that shines through.
Great suggestions on planning and optimizing your printing and scanning results can be found in our FAQ section.
By downloading any STL-file from this site, you agree to abide by this license CC BY-NC-ND 4.0 Non Commercial-NoDerivates 4.0 International.
The components used for this design can be found at https://www.amazon.de/-/en/hz/wishlist/ls/2W3O8XTIXYNA4?ref_=abls_nvfly_yl
